Notes
This axle comes with 2 spacers to accommodate multiple axle bearing options. The spacer needs to be installed before the bearing is pressed on: The thin spacer (½") is used with sealed RW507CR bearings, and the thick spacer (.826") is used with set 9 bearings.
•Lug Diameter 4.75
•Hub Diameter 2.78
•Float Type Bolt-In
•Bearing Diameter 1.380
Fitment:
Pontiac Tempest (1964-1970)
Pontiac GTO (1964-1972)
Pontiac Grand Prix (1964-1972)
Pontiac Catalina (1964-1972)
Pontiac LeMans (1965-1971)
Pontiac Bonneville (1964-1972)
Pontiac Firebird (1967-1972)
Compatible Differentials
GM 8.2" Rear for Buick, Oldsmobile & Pontiac
