Specifications:
•Rated Line Pull 10,000 lbs. (4536 kg) single-line
•Motor 12V DC, 6HP Series Wound
•Electrical controls Contactor
•Remote Control Remote switch, 12’ (3.7m) lead
•Geartrain 3 Stage Spur Gear
•Gear ratio 134:1
•Clutch (freespooling) Sliding motor pinion gear
•Brake Automatic disc type
•Drum diameter/Length 3.5”/8.5” (9cm/22cm)
•Rope M8274: 3/8” x 125’ Steel rope
•Replacement Rope M8274: 3/8” x 125’ Steel rope - Replacement PN 106141
•Fairlead M874: Roller Fairlead
•Recommended Battery 650 CCA minimum for winching
•Battery leads 2 gauge, 72” (1.83m)
•Finish Powder coat with clear coat
•Weight M8274-S, M8274: 90lb (40.8kg)
•Warranty Limited lifetime (mechanical components); seven year (electrical components)
