Specifications: Features:
Voltage: 12 Volts - Permanent Magnetic Motor
Max Amperage: 40 Amps - Stainless Steel Valves
MAx Duty Cycle: 100% @ 100 PSI - Moisture & Dust Resistant
Max Wroking Pressure: 200 PSI - Stainless Steel 3/8" Leader Hose
Length (Each): 11.5 in (292.1 mm) - Insulated Wiring with Connections
Width (Each): 4.3 in (109.22 mm) - Mounting Plates with Vibration Isolators
Height (Each): 6.5 in (165.1 mm) - Intake Filter Assembly
Weight (Each): 11 lbs (4.99 Kg) - Installation Instructions
**This air compressor kit is designed to handle up to a 10 gallon air tank. Using this compressor with a larger tank, pressure over 200 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
