Specifications: Features:
Voltage: 12 Volts - Permanent magnetic Motor
Max Amperage: 40 Amps - Stainless Steel Valves
Max Duty Cycle: 100% @ 100 PSI - Moisture & Dust Resistant
Max Working Pressure: 150 PSI - Stainless Steel 1/4" Leader Hose
Length (Each): 11.25 in (285.75 mm) - Insulated Wiring with Connections
Width (Each): 4 in (101.6 mm) - Mounting Plates with Vibration Isolators
Height (Each): 6.75 in (171.45 mm) - Intake Filter Assembly
Weight (Each): 9.75 lbs (4.4 Kg) - Installation Instructions
**This air compressor kit is designed to handle up to a 10 gallon air tank. Using this compressor with a larger tank, pressure over 150 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
