Specifications: Features:
Voltage: 12 / 24 Volts - Permanent Magnetic Motor
Max Amperage: 19 / 10 Amps - Stainless Steel Valves
Max Duty Cycle: 33% @ 100 PSI - Moisture & Dust Resistant
Max Working Pressure: 150 PSI - Stainless Steel 1/4" Leader Hose
Length: 7.4 in (188 mm) - Insulated Wiring with Connections
Width: 3.94 in (100 mm) - Mounting Plates with Vibration Isolators
Height: 6.75 in (171.5 mm) - Intake Filter Assembly
Weight: 6.95 lbs (3.15 Kg) - Installation Instructions
**This air compressor is designed to handle up to a 5 gallon air tank. Using this compressor with a larger tank, pressure over 150 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
