Specifications: Features:
Voltage: 12 Volts - Permanent Magnetic Motor
Max Amperage: 16 Amps - Stainless Steel Valves
Max Working Pressure: 150 PSI - Moisture & Dust Resistant
Max Duty Cycle: 30% @ 100 PSI - Stainless Steel 1/4" Leader Hose
Length: 7.13 in (181 mm) - Insulated Wiring with Connections
Width: 3.94 in (100 mm) - Mounting Plates with Vibration Isolators
Height: 6.34 in (161 mm) - Intake Filter Assembly
Weight: 6.6 lbs (2.99 K - Installation Instructions
***This air compressor is designed to handle up to a 5 gallon air tank. Using this compressor with a larger tank, pressure over 150 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
