Features
Permanent Magnetic Motor
Oil-less Design
High Performance PTFE Piston Ring
Stainless Steel Valves
Moisture & Dust Resistant
Gearless Direct Drive Motor
Anodized Aluminum Alloy Cylinder
Automatic Reset Thermal Overload Protector
Mounting Plates with Vibration Isolators
Stainless Steel 1/4 in Braided Leader Hose
In-line Check Valve
Intake Filter Assembly
Insulated Wiring with Connectors
Installation Instructions
Specifications:
Voltage: 12 volts
Max Amperage: 18 amps
Maximum Duty Cycle: 25 % @ 100 PSI
Maximum Working Pressure: 150 PSI
Maximum Restart Pressure: 200 PSI
CFM @ 0 PSI: 2.03 CFM
CFM @ 100 PSI: 0.76 CFM
Length: 6.71 in (170.5 mm)
Width: 3.28 in (83.2 mm)
Height: 5.08 in (129 mm)
Weight: 5.1 lbs (2.31 Kg)
**This air compressor is designed to handle up to a 2.5 gallon air tank. Using this compressor with a larger tank, pressure over 150 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
