Specifications: Features:
Voltage: 12 Volts - Permanent Magnetic Motor
Max Amperage: 14 Amps - Stainless Steel Valves
Max Duty Cycle: 15% @ 100 PSI - Moisture & Dust Resistant
Max Working Pressure: 130 PSI - Stainless Steel 1/4" Leader Hose
Length: 6.35 in (161.3 mm) - Insulated Wiring with Connections
Width: 3.28 in (83.4 mm) - Mounting Plates with Vibration Isolators
Height: 4.95 in (125.7 mm) - Intake Filter Assembly
Weight: 3.50 lbs (1.59 Kg) - Installation Instructions
**This air compressor is designed to handle up to a 1 gallon air tank. Using this compressor with a larger tank, pressure over 130 PSI, or without a pressure switch not only voids your warranty but may reduce the lifespan of your compressor.
