Recommended for Maximum Performance:
-650CCA Battery for maximum power
-Snatch block/pulley block to double line for loads over 5000lbs
-----------------------------------
-Pull Speed & Amps
Line Pull lbs...Line Speed ft/min...Current (Amps)
0...........................22..............................80
4000....................12..............................200
6000....................9................................270
8000....................6.5.............................330
-----------------------------------
-Line Pull and Rope Capacity in Layer
Layer...Rated Line Pull (lbs)...Total Rope on Drum (ft)
1.......................8000............................19.6
2.......................6540............................42.6
3.......................5500............................72
4.......................4750............................100
