Power Source: 12VDC
Single line rated pull: 10,500lb (4773kg)
Motor: 6.5hp Series Wound (4.9kw)
Solenoid: IP67 Rated against dust and water
Wired Remote: Wired Remote switch, 12ft (3.7m) lead
Wireless Remote: RF Wireless Remote, 30ft (9.14m) range
Gear train: 3 Stage Performance Planetary Gear Train
Gear Reduction Ratio: 218:1 for incredible line speed
Clutch: Sliding Ring Gear
Braking Action: Automatic In-The-Drum
Drum size: Drum size Diameter 2.5"(63.5mm ) Length 8.8"( 224mm)
Synthetic Rope: 88ft of 7/16" diameter (26.5m of 10.5mm) Rated 7.5 tons or 16,500lb
Fairlead: Aluminum Hawse Fairlead
Mounting Pattern: 4.5” x 10” bolt pattern (114.3mm x 254mm)
Battery Recommended: 650CCA minimum for winching
Battery Leads: 2 gauge 72"(1.83m)
Net Weight: 62lb (28kg)
Gross Weight: 66lbs (30kg)
