Specifications
Nominal Operating Voltage 12 Vdc
Dimensions(L x W x H) 21" x 7" x 11"
Net Weight (Lbs) 65
Motor Type Series Wound
Operating Temperature Range -20℃ (-4℉) to 65℃ (150℉)
Max Pressure 200 psi
Max Restart Pressure 150 psi
Current at Max Pressure (200 psi) ≤190 amps
Flow Rate @ 100 psi ≥8 cfm
Duty Cycle @ 100psi @ 21℃ (70℉) 100% continuous
Typical Performance (cold, at sea level)
PSI CFM Current
0 15 110
50 10 140
100 9 170
Flow rate decreases as operating temperature and/or altitude increase.
Exclusive Features•Direct Port Intake Design - Stabilizes airflow for maximum performance.
•Dual-Ring, Oil Control Pistons - Significantly reduces oil by into air supply.
•Oil Reservoir Chamber - Provides relief for crankcase oil transfer and expansion.
•Oil Reservoir Baffle - Acts as an air/lubrication separator.
•Oil Sight Glass - Offers a quick visual check of crankcase lubrication.
•Motor Cooling Fan - (XD3000) airflow through the motor reduces extended use heat build-up.
•Control Wire - Connection point for optional pressure switch and/or dash switch.
•Low Voltage Cut-off - "Smart" technology turns compressor off if voltage drops to protect motor.
•Power Switch - With indicator light.
•Low Voltage Indicator - Alerts when battery or system voltage is low.
•High Flow - Swedish Steel valves.
•Air Filter - High-flow, long-life filter with serviceable element.
•Deep Finned Heads - Dramatically reduces compressor operating temperature.
•York® Compressor - Modified, twin-cylinder, 10 cubic inch industrial unit.
•HD Roller Bearings - At both ends of crankshaft.
•Mounting Plate (optional) - Provides a direct drive connection.
•Heavy-duty Coupler - Provides a direct drive connection.
•12 VDC Industrial Motor - Hi-performance, commercial duty.
•Motor Cooling Exhaust - Reduces motor heat buildup. (XD3000)
•Power Cables - 10' of #4 AWG cables.
