Features:
•Balanced & Blue Printed Rotating Assembly
•Sim Tested Short Block
•Wagler HD Forged Connecting Rods
•Fly Cut, Coated & Chamfered Pistons
•*Pistons have .010 cut off the top & .100 Valve Reliefs
•14mm Gorilla Girdle w/ ARP Main Studs
•Balanced Cummins Crank
•Industrial Injection Stage 2 Cam
•Cam Bearings Installed In All Journals To Prevent Cam & Block Wear
•Coated H Series Main & Rod Bearings
•Billet Freeze Plugs
•Premium Killer Dowel Pin Kit
•New Oil Pump, Water Pump & Oil Cooler
•New Oil Pickup Tube
•Big Iron Stamped Oil Pan
Cylinder Head Specs:
•12 Valve Stage 2 Cylinder Head w/ Fire Ring Grooves
•Hand Blended CNC Porting On Valve Bowls, Intake & Exhaust ports
•Intake Shelf Machined Off To Accept ZZ Fab Side Runner
•New Diamond Honed Valve Guides
•New Stainless Steel Valves
•Radius Cut Fire Ring Head Gasket
•Milled & Surfaced Fire Ringed Head
•ARP 625 Head Studs
•150lb Performance Valve Springs
•Comes With Rocker Assembly & Stock Pushrods (upgraded pushrods available)
•Drilled & Tapped Coolant Freeze Plugs
•Rated for 1,500 horsepower.
*One Year Warranty
*Verify Year
*Does not come with valve covers
*Does not come with additional gaskets for assembly
*Does not come with ZZ Fab Side Runner
*All Industrial Injection short blocks and long blocks are required to be ran with Joe Gibbs Break In Oil (not included) for the initial 300-500 miles.
