Features
•Forged Milled Billet Wheel
•Custom built to BD specifications, not a box turbo
•Quick spool-up with no surging
•Cooler EGTs & less smoke
•Special low inertia, full-floating 6-pad thrust bearings, not 3 pad like box turbos
•Dual volute T3 turbine housing utilizes low rpm exhaust pulses for improved turbine response
•Efficient positive boost-to-drive pressure ratio yields high power with low EGTs
•Perfect fitment to the stock turbocharger inlet connection points
•BD's HD Waste gate and bracket holds boost and prevents over speed damage
•Turnbuckle Boost Control allows for ease of adjustment for altitude and extreme tuning
•Most systems can be upgraded to a twin system for more power or even better towing performance
•870 CFM / 450 HP
•Comp Wheel: 58mm 2.28in
•A/R Ratio: 0.80
•Downpipe, V-Band Clamp, Band Clamp
•Turbine Wheel: 74mm 2.91in
INSTALL TIME
4 Hours
WARRANTY
Parts
•12-Months
•12,000 Miles
NOTE
•Not for sale on licensed California vehicles
•Turbo mount exhaust brake cannot be installed with this kit - use remote mount exhaust brake
EMISSIONS
This product has met EPA's reasonable basis requirements and is legal for sale and use within the jurisdiction of the federal EPA. (EMS:2)
